General Features

Type Online Single Phase (VFI)

Phases (IN-OUT) 1-1

Form Factor Rack, Tower

Rack Units [U] 2U

Power Capacity 3000VA / 3000W

Output Power Factor 1

Input

Input Voltage Range 160-300V 100% load, 110-160V derating to 50% load linearly

Max THDi ≤5%

Frequency Range 40Hz – 70Hz

Frequency (Synchronized Range) 45Hz – 55Hz or 54Hz – 66Hz @ load > 60%

DC Input (PV)

Input Power Factor > 0.99 @ full load

Output

Waveform Pure Sine Wave

VA 3000

Load Crest Ratio 3:1

Nominal Output Voltage 200/208/220/230/240 VAC (derating 10% @ 208V, derating 20% @ 200V)

THDv ≤1% @ 100% linear load, ≤5% @ 100% non-linear load

Frequency (Battery Mode) ±0.2Hz

Output Power Factor 1

Input and Output Connectors

Input Connector C20-UK

IEC C13 8

IEC C19 1

Technical Details

LINE Mode Efficiency [%] (Full Load) 93.0

ECO Mode Efficiency [%] (Full Load) 97.0

Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] 10ms

Transfer Time (AC / Line Mode to Battery Mode) [ms] 0ms

Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] 10ms

Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] 4ms

Load Crest Ratio 3:1

Additional Features CVCF Mode Available, Potential Equalization Screw, Hot-Swappable Batteries, OBM – Optimized Battery Management, LCD Display, Unity Power Factor 1.0, Battery Pack Available, IoT – Cloud Connectivity, Generator Compatible, EPO – Emergency Power Off, Programmable Segment Available, HID – Human Interface Device, EBM – External Battery Module – Auto Detection

IEC 62040-3 classification VFI-SS-311

Batteries and Autonomy

Batteries 6x 12.0V/9.0Ah

DC Voltage 6x 12.0V

Recharge Time 3h to 90%

Full Load Backup Time [min] 3.7

Half Load Backup Time [min] 10.1

Charger 1.5A

External Battery Pack Anderson PP45 x2

Recharge Time 3h to 90%

Communication

Communication Dry contact, RS-232, WLAN Port – for Internet Connection, Management Card Slot, RJ-45 – for Internet Connection

Software WinPower

Management and Environment

Software WinPower

Communication Dry contact, RS-232, WLAN Port – for Internet Connection, Management Card Slot, RJ-45 – for Internet Connection

Noise Level < 50dB

Fan Logic Always on, Automatic Speed Control

Temperature 0°C – 40°C

Humidity 0% – 95% RH (non-condensing)

IP IP 20
